Installing solar panels is an investment that should work for decades. However, house or business owners in Kyiv and across Ukraine often forget one key aspect — the calculation of the load from solar panels on the roof’s load-bearing structures. Many believe the weight of photovoltaic modules is insignificant, but engineering practice proves that without prior mathematical modeling, SPP installation can turn into a dangerous experiment threatening the integrity of the entire building.

Why Visual Inspection is Not Enough

When you mount a solar power plant (SPP), you add more than just the weight of the panels to the roof. Together with mounts, profiles, and ballast systems (if talking about a flat roof), a substantial mass is added. Furthermore, engineering calculation must account for:

1. Snow load. Panels hinder the uniform shedding of snow, creating local zones of “snow pocket” accumulation. Building codes provide limit values for different regions of Ukraine: south — ≈ 80–90 kg/m², central regions — ≈ 120–150 kg/m².
2. Wind pressure. During strong wind gusts, solar panels act as a sail, creating colossal uplift forces transmitted to the roof rafter system.
3. Dynamic oscillations. Structural vibrations arising during storm-force winds.
4. Additional operational loads arising during the installation and maintenance of the system.

GBU specialists conduct a full technical audit before granting permission for mounting. More about technical roof inspection for SPP.

How GBU Performs Calculations

We do not rely on guesswork. GlobalBud Ukraine engineers use modern load modeling software that considers the climatic characteristics of your region (zoning for snow and wind load according to DBN V.1.2-2:2006 “Loads and Influences”). If the calculation shows that existing rafters cannot withstand the load, we develop a reinforcement project. What is included in our calculations:

1. Determining the total SPP weight (panels + mounts + ballast). Approximately, one solar panel can weigh 20–30 kg.
2. Verifying the sections of wooden or metal roof frame elements.
3. Calculating forces acting on fastening nodes.
4. Analyzing the strength safety margin of supporting walls and foundations (if necessary).
5. Assessing the actual technical state of load-bearing structures.

It is important to remember that post-war roof inspections in Ukraine have their nuances, as even visually intact structures may have lost part of their load-bearing capacity. Order a professional roof inspection.

Factors Influencing Roof Load-Bearing Capacity

A common mistake is assuming that if there is enough space on the roof, the SPP can be installed without additional checks. In reality, roof load-bearing capacity depends on many factors:

• building type and purpose;
• year of construction and structural wear;
• floor slab material and its actual state;
• presence of corrosion, cracks, deflections in metal or reinforced concrete elements;
• previous repairs or remodeling that could have altered the structural scheme;
• actual state of the roofing layer and waterproofing.

Roof load-bearing capacity check is a comprehensive procedure that answers the main question: is it safe to mount an SPP on your object.

Step-by-Step Algorithm for Load Calculation

The load calculation process for solar panels is performed by a structural engineer according to the following algorithm:

1. Determining panel placement area — how many square meters of the roof will be utilized.
2. Calculating the mass of photovoltaic modules — taking into account the quantity of panels and their technical specifications.
3. Calculating the mass of the mounting system — profiles, fasteners, cable trays.
4. Choosing the mounting or ballasting scheme — different approaches are applied for pitched and flat roofs.
5. Determining design snow and wind loads for a specific region according to DBN.
6. Assessing the actual technical state of load-bearing structures — based on visual and instrumental inspection.

The final conclusion is made not based on the weight of an individual module, but based on the total load per square meter of roof and the ability of the structures to support it.

Consequences of Incorrect Load Calculation

Ignoring professional load calculation can lead to serious problems:

• rafter system deformation — beam deflection, cracks in wood or metal;
• destruction of the waterproofing layer — leaks leading to additional repair costs;
• foundation overloading — especially relevant for old buildings with worn-out support structures;
• panels blowing off during strong winds — due to incorrect wind load calculation;
• inability to obtain insurance — the insurance company may refuse payment if damages occurred due to improper mounting.

Follow our news regarding changes in legislation and technical requirements for solar panel installation.

Frequently Asked Questions (FAQ)

Can panels be installed on a roof if the calculation shows a strength deficit?

Yes, we develop a structural reinforcement project (metal beams, additional supports), which allows safe mounting of a system of any complexity. Such a solution is often more economically advantageous than total roof replacement.

Is wind accounted for in calculations?

Absolutely. Aerodynamic loads are often the main factor that can damage not just the panels, but rip off part of the roof. Wind load is calculated in accordance with DBN V.1.2-2:2006, considering building height, terrain type, and roof configuration.

How often should load inspection be conducted after SPP installation?

It is recommended to conduct a planned technical inspection every 5 years, as well as after extreme weather events (hurricanes, anomalous snowfalls). This allows timely detection of possible deformations and extends the service life of the entire system.
